MARIN ALPINE TRAIL E1 FULL SUSPENSION ELECTRIC MOUNTAIN BIKE 2021 OVERVIEW
This Marin Alpine is mountain biking on stilts. Beyond capable, both up and down, in even the most challenging terrain. If you’re looking for a bike that maximises fun, park yourself up right here.
BT-8035, Internal 504Wh
Shimano STEPS E7000, 250W, 60Nm
SC-E7000 Display
Marin Alpine Trail E1 Full Suspension Electric Mountain Bike 2021
The Alpine Trail E will take you further, faster, allowing you to tackle the most aggressive trails either up or down.
MIXED WHEEL SIZES - 29” front and 27.5”+ rear wheel sizes are the ideal combination for the Alpine Trail E, with larger front wheel easily rolling over most any trail obstacle and offering the best cornering traction, while the burly 27.5” x 2.8” rear setup adds playfulness and enhances acceleration and braking traction.
DROPPER POST OPTIMISED - The modern day trail rider needs their saddle out of the way at times, while low-slung frames require longer length posts.
SEAT TUBE LENGTHS HAVE BEEN MINIMISED - Add to this minimum insertion depths, and riders of all sizes will get the proper extension needed.
Detail
MARIN ALPINE TRAIL E1 FULL SUSPENSION ELECTRIC MOUNTAIN BIKE 2021 OVERVIEW
This Marin Alpine is mountain biking on stilts. Beyond capable, both up and down, in even the most challenging terrain. If you’re looking for a bike that maximises fun, park yourself up right here.
ELECTRIC SPEC:
| Motor | Shimano STEPS E7000, 250W, 60Nm |
|---|---|
| Battery | BT-8035, Internal 504Wh |
| Display | SC-E7000 Display |
| Switch | SW-E7000 Left Hand Switch for Assist Mode Change |
| Extras | Shimano Battery Charger EC-E6002, Bolt-on Thru-Axle |
SERIES 4 ALUMINUM FRAME
Alpine Trail E models are built upon Marin’s Series 4 aluminium frames, with detailed forgings, highly manipulated tubes, and full internal cable routing, giving you the highest-end alloy frame that they offer, compatible with modern coil or air shocks.
MULTITRAC SUSPENSION
The Alpine Trail E features the same great, proven MultiTrac suspension technology, but optimised for the Shimano STEPS system.
NO NEED FOR PLATFORM OR LOCKOUT LEVERS
Just get on and blast up the hills.
Geometry & specification
| Frame | All New Series 4 Alloy Frame, 150mm Multitrac suspension, Integrated Battery/On-switch/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor |
|---|---|
| Rear shock | Rock Shock Super Deluxe Coil R, Rebound Adjustment, 205x65mm, 25mmxM8 Lower Hardware, S/M Spring Rate = 300lb, L/XL Spring Rate = 400lb |
| Fork | Rock Shock 35 Gold RL 29", Motion Control Damper, 160mm Travel, Maxle Stealth Axle, 44mm Offset |
| Headset | FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| Shifters | Shimano Deore M4100-R, I-Spec EV, 10-Speed |
| Front derailleur | None |
| Rear derailleur | Shimano Deore 5100 Direct Attachment, 10-Speed |
| Chainset | Marin Forged Alloy 165mm Length, Narrow Wide 38T Chainring, e13 Plus Chain guide, Aluminum Plate |
| Bottom bracket | |
| Chain | KMC X-10E, E-Bike Specific, Silver |
| Cassette | Shimano Deore M4100-10 10-speed 11-46T |
| Wheelset | Front: Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible; Rear: Marin Aluminum Double Wall, 27.5" Diameter, 38mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible |
| Hubs | Front - Shimano MT-410B, 110x15mm, Centerlock Disc, 32H, Rear - Shimano HB-MT400B, 148x12mm, Centerlock, Standard Freehub Body |
| Spokes | 14g Black Stainless Steel |
| Tyres | Front: Maxxis Assegai 29x2.5", 3C MaxxTerra, Double Down, Tubeless Compatible Rear: Maxxis Minion DHR II 27.5x2.8, 3C Maxx Terra, EXO+, Tubeless Compatible |
| Brakes | Shimano MT420, 4-Piston Hydraulic Disc Brake, 203mm Rotor |
| Handlebars | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back |
| Grips | Marin Single Clamp Locking |
| Stem | Marin 3D Forged Alloy, 35mm |
| Saddle | Marin E-MTB Saddle |
| Seatpost | TranzX, YSP23JL, 1x Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm |
| Pedals | Marin MTB Plastic |
Get the right fit
3D Bike fitting at Sprockets Cycles by Kinetic 365
No matter your age, fitness level or style of riding, the importance of getting the best bike fit is key to getting the most out of your bike and also looking after your health.
A bike fitting at Sprockets Cycles is a massive opportunity for you to take a huge leap forward in your cycling journey. In partnership with expert bike fitter Scott Maclean, owner of Kinetic 365 Coaching, you will have your bike personally and professionally fitted.
Call Scott direct on: 07933 158473
Email Scott direct on: kinetic365coaching@gmail.com
Call Sprockets Cycles direct on: 01563 526800
Email Sprockets Cycles using the button below or direct at: info@sprocketscycles.com
