Marin Alpine Trail XR Full Suspension Mountain Bike

Marin Alpine Trail XR Full Suspension Mountain Bike

The Alpine Trail series is Marin's boldest and most capable line of enduro bikes ever, built upon their most advanced, most adjustable frames to date.

Series 4 aluminium MultiTrac 2 LT frames feature mixed 29”/27.5” wheels, 170mm front and 160mm rear travel, and the utmost in adjustability. Riders can alter the head tube angle and bottom bracket/chainstay length, as well as run 29” rear wheels if desired. “Bear Box” downtube storage includes a zippered nylon bag to house trail essentials, and a 34.9mm seatpost increases strength and is compatible with the latest dropper posts.

"XR" = "Xtra Rad" at Marin, and like the XR models that have preceded the new Alpine Trail, they created a model for the more discriminating rider. Marin focused their efforts on building a bike with high performance RockShox Ultimate-level suspension, a SRAM GX Eagle Lunar 12-speed drivetrain and DB8 4-piston brakes - all equipment that helps the rider level up, but without blowing the budget. Don't forget the Maxxis rubber and Marin's proprietary CNC machined 35mm stem and matching Trail Bar.

Key Upgrades from previous model:

• RockShox Zeb Ultimate/RockShox Super Deluxe Ultimate suspension
• SRAM GX Eagle Lunar drivetrain
• SRAM DB8 4-Piston hydraulic disc brakes
• Maxxis Assegai Tires
• Marin Trail Bar & CNC Stem

MULTITRAC 2 LT

MultiTrac 2 LT debuts on the aluminium-framed Alpine Trail alloy models. MultiTrac 2 LT shifts from seatstay pivots to chainstay pivots, ensuring that the suspension performance matches Marin's design goals, which are not achievable using pivots located on the seatstay once travel exceeds 150mm. With MultiTrac 2 LT, the benefits of relocating the rear pivot points from the seatstay to the chainstay become apparent, as it reduces anti-rise, allowing for better chassis control while braking, more mid-stroke support, and better feel at bottom out.

ADJUSTABLE GEOMETRY

With the integrated flip chips, adjustable headset and an aftermarket 29” rear wheel, Alpine Trail aluminium riders can select 12 unique configurations to run their bikes. These configurations allow the best fine-tuning of chassis to trail conditions available. Flip chips are easy to reconfigure trailside and easily done using a 6mm hex wrench, require no additional parts, and incorporate laser-etched graphics that indicate the position of the chips. The stock 27.5” rear wheel can be swapped out for a 29” rear wheel (not included) if desired, along with changing the position of the seatstay flip chips. Furthermore, the flip chips located at the seatstay pivots alter the bottom bracket height and chainstay length (low BB/long CS setting = 345/442mm, high BB/short CS setting = 352/435mm) so that riders can perfectly dial their bike in to match the terrain they are looking to conquer.

Bear Box Downtube Storage

The all-new Alpine Trail aluminium models now feature Marin's Bear Box integrated downtube storage, complete with a custom nylon bag with a weather-sealed zipper. The hatch door is secure and double-sealed, with bottle bosses. Keep your riding essentials safe and protected from the elements during your big ride.

ADJUSTABLE HEADTUBE ANGLE

Using proprietary headset cups and inserts, the headtube angle on Alpine Trail aluminium models can be adjusted to +0.75° or -0.75° from the standard 63° position, giving the rider three options.

PROTECTION

Chainstay and seatstays are protected with durable rubber guards that minimise noise and protect paint finishes, and integrated downtube guards helps deflect errant rocks, logs, or anything else riders may encounter on the trail.

Additionally, all aluminium frame models include a gasket around the cable exit hole reduces noise and prevents the brake hose and derailleur cable from marring the frame, and a mudflap positioned over the lower suspension pivot keeps spray and muck off the bearings. Cable ports are of an all-new design and keep the frame innards sealed. These ports use rubber membranes punctured during initial assembly and seal around the housing or hose once inserted. They will be available as a service part for when riders make changes to their components.
